Lithium ion Battery 36V 20Ah Pack for 350W 500W 750W 1000W Electric

Rechargeable Lithium li-ion Battery Pack36 Volt 20Ah/20000mAh for 36V 200W 250W 300W 350W 400W 450W 500W 600W 750W 800W 1000W Electrice-bike Scooter Bicycle Hub Motor Kit E Bike Conversion Kit 10s 30Amp BMS 10s7p Battery T Deans Connector(12Awg)USA Stock    The batteries we are selling are the upgraded battery, the cells are better than before, the quality of the raw materials is also better than before, and we added the frame for batteries to prevent them from exploding due to impact. Now the battery is safer and more reliable. And we have optimized the production process and testing process, the service life will be longer.   Description*Type: Lithium li-ion Battery Pack Rechargeable* Battery Voltage: 36Volt* Charge Voltage : 42Volt* Capacity (amp hours) : 20Ah* Peak Discharge current : 75Amp* Continuous DischargeCurrent : 30Amp* Fit ebike: For 36V 200W 250W 350W 400W 480W 500W 750W 800W900W1000Watt ebike kit* Long life1500+cycles,Quality Grade A+++++ cell, Riding time longer than ordinary batteries.  * Built in BMS with short circuit , over-current , over-heat , over-charge , over-discharge protection.* Short Circuit Safety Test √ Overcharge and Overdischarge Safety Test √ Vibration Safety Test √ Flame Retardancy Safety Test √ Extrusion Safety Test.  SIZE & WEIGHT ADVANTAGE* Size (L x W x H): 225*142*70mm/ 8.9*5.6*2.8inch* Weight: About :3.53kg/7.58lb Specification

Battery Model

36V 20Ah

Nominal Voltage (V)

36V

Nominal Capacity (AH)

20Ah

Cell Combination

7-parallel 10-series

Cell Current (A) 2.5 - 3A

Cell Size

3.7V

Cell Quantity (parallel*series)

70pcs

Charge Cutoff Voltage (V)

42v

Rated Discharge Current (A)

32A

instantaneous Maximum Discharge Current (A)

75A

Continuous Discharge Current (A)

30A

Charger
 42V 2A 5.5mm x 2.1mm DC Adapter

Standard Charge Current (A)

2A

Charge Time under Standard Charge Current

8hours

Fast Charge Current (A)

4A/5A

Charge Time under Fast Charge Current

4hours to 4.5hours

Charge Temperature Range

 0-55°C/32-131°F

Cell Size (L*W*T )

225*142*70mm/ 8.9*5.6*2.8inch

Battery Weight

About 3.53kg/7.58lb

Fit ebike

200W/250W/350W/400W/450W/

500W/750W/800W/1000W(Max)

Application  Electric bicycle, Electric scooter, Golf electric car，Motor，Electric Bike（E Bike，Ebike） Feature SAFETY & PROTECTION ADVANTAGE* Built in Automatic Battery Protection System Internal* Automatic Low Voltage Disconnect : 25V* Automatic Short Circuit Protection Instant* Automatic Over Voltage Protection : 42V* Flame Retardant Electrolyte : Yes* Length Way Circuit Boards : Yes* Automatic Internal Cell Balancing : Yes* Explosion Proof Polymer Cells :Yes TECHNOLOGY ADVANTAGE* Usable Capacity (AH): 20AH* Depth of Discharge : 100% DOD* Reserve Minutes @ 10A 60 min* Self Discharge <3% per month* Cell Type : A+++++* Cell Combination : 10 Series and 7 Parallel(10s7p) SAFE & DURABLE ADVANTAGES
 * Fully automatic built in battery protection system
* Long life 1000 - 2000 cycles
* Lightweight - up to 70% lighter than lead
* No voltage sag - faster cranking for motors and higher voltage for continuous consistent power.
* Dry Battery - no toxic lead or acid
* Green ROHS compliant - No Lead  Package includes* 1 x 36V 20Ah Lithium li-ion Battery for 200W-1000W ebike
* 1 x T Deans Connector(12Awg)
* 1 x 30A BMS (BMS is built in the battery pack* NO Charger    Note1. Due to manual measurement, the size will have an error of 1-3mm.
2. Standard lithium battery charger must be used.
3. Prohibit large current discharge.
4. Do not remove or short circuit the battery which is most likely to cause short circuit.
5. Please carefully check the battery fit range and size before buying to avoid unnecessary returns.
